Room Temperature Curing Polyurethane materials is Bi-component. A is polyol component, and B is MDI-terminated prepolymers.
Room Temperature Curing Polyurethane resin has excellent processing properties, cured under room temperature, short demould time, and the color can be changed by adding pigment. The final polyurethane products are transparent which enjoy good abrasion resistance, water resistance, good resilience. The hardness is in the 30 to 93 shore A hardness range.
Product Specification
|
Model |
30A/B |
60A/B |
80A/B |
93A/B |
|
|
Status in 20℃ |
A |
Yellow transparent liquid |
|||
|
B |
Colorless transparent liquid |
||||
properties of polyurethane resin
|
Component B |
Type |
BQ5631B |
|
Apprarance |
Transparent colorless liquid |
|
|
Component A/C |
Type |
BQ5631A/BQ5631C |
|
Apprarance |
Transparent colorless liquid |
|
|
Ratio B:A:C (by weight) |
100: (50:10) |
|
|
Operate Temprature (30℃) |
25~35 |
|
|
Gel time (min/30℃) |
2~3min |
|
Operation introduction
|
Mixing ratio(A:B) |
1: 1 |
||||
|
Mixing temperature(℃) |
35-50 |
||||
|
Viscosity in 50℃(mpa•s) |
A |
300 |
400 |
500 |
800 |
|
B |
900 |
800 |
700 |
500 |
|
|
Gel time (min) |
50 |
30 |
10 |
3 |
|
|
Post curing time(80℃/h) |
12 |
12 |
6 |
6 |
|
Physical Properties
|
Hardness(Shore A) |
30±2 |
60±2 |
80±2 |
93±2 |
|
Tensile strength(MPa) |
3 |
7 |
16 |
30 |
|
100%Modulus(MPa) |
0.5 |
2 |
4 |
8 |
|
300%Modulus(MPa) |
1.5 |
3 |
8 |
15 |
|
Elongation at Break(%) |
700 |
500 |
450 |
450 |
|
Right-angle Tear strength (KN/m) |
5 |
12 |
40 |
85 |
|
Rebound(%) |
60 |
50 |
40 |
35 |
|
Specific gravity(25℃) (g/cm³) |
1.10 |
1.11 |
1.12 |
1.15 |
Operation by manual
1. Take certain A component to make reserve.
2. Calculate B component to make reserve.
3. Pour B component to A component and stir evenly.
4. Cast the mixture of step 3 to the mould.
5. Open the mould when the product is hard.
6. Post cure 16 hours at 100℃.
Note: The mixture in the step 3 can be vacuumized to get rid of bubble.
Operation by casting machine
1. Put some A component into A tank, vacuumize to make reserve.
2. Put some B component into B tank, vacuumize to make reserve.
3. Cast the two materials according the ratio to the mould.
4. Open the mould when the product is hard.
5. Post cure 16 hours at 100℃.
Safety
Use in a well ventilated area. Avoid contact with skin using protective gloves and protective clothing. Repeated or prolonged contact on the skin may cause an allergic reaction.
Eye protection is extremely important. Always use approved safety glasses or goggles when handling this product. If Contact Occurs:
Skin: Immediately wash with soap and water. Remove contaminated clothing and launder before reuse. Seek medical attention if allergic reactions occur.
Eyes: Immediately flush with water for at least 15 minutes, contact a physician.
Ingestion: If swallowed, contact a physician immediately. Remove stomach contents by gastric suction or induce vomiting only as directed by medical personnel.
Never give anything by mouth to an unconscious person.
CAS NO. : 9009545
HS code: 390950
